PATENTED

Patent n°
102020000028661

REVOLUTION IN CLEAN EDGES AFTER LAMINATION

The RD CLEAN CONCEPT bag, manufactured from selected and special materials, allows finished glass to be obtained by limiting interlayer leakage to zero

SAVE TIME AND LABOUR

For glass edge cleaning with significant cost optimization

SAFETY FOR THE OPERATOR

who does not have to use sharp tools.
Installed on ovens of other brands with excellent results.

Clean edge after lamination? Done!

The innovative post-lamination, clean-edges system based on a laminating bag of last generation. It is a real system manufactured with special materials, selected to respond to a particular scope: to limit the excees of the laminating interlayer from the glass edges after lamination.

This system provides several benefits in production among which:

  • Saving time and labor by removing one step in lamination
  • Safety of the operator who does not need to use sharp tools
  • Installed in different kilns with excellent results”

Clean edge after lamination

Perfect interlayer thickness at the end of the lamination process

Savings of about 40% on labor costs

Unit of
measure
ValuesTest method in accordance with
MaterialSilicone
rubber
Specific weightgr/cc 1,16 DIN 53479
HardnessSh.A 50 ± 5DIN 53505 (3”)
Breaking loadN/mm29,4DIN 53504
100% moduleN/mm21,2DIN 53504
200% moduleN/mm21,7DIN 53504
300% moduleN/mm22,3DIN 53504
Elongation at break%690DIN 53504
Tear resistanceN/nm40ASTM D 624 B
Temperature resistenceLimit+280°C
Temperature resistenceExercise+260°C
High adhesion capacity to the most complex shapes with moderate effort
High resistance to tearing
Higher performance with high temperatures
Good resistance to compression.

According to standards in matter of dimensions and edges finishing
Rif: UNI EN ISO 12543-5:2022

  • glass in bulding
  • laminated glass
  • safety laminated glass
